of surrounding cells, thus data were imputed separately for attributes and outcomes. This prevented circular rea-
soning and the introduction of spurious relationship between attributes and outcomes.
The overall management success score (OMS) was computed including the imputed (missForest) outcomes.
We assessed the strength and significance of the correlative relationships between the OMS, the 3 outcomes and
43
42
the 20 attributes (i.e. predictors) by using random forests and the Boruta add-on algorithm . The random forest
method was suitable for our dataset because it can cope with small sample sizes, a large number of predictors,
complex interactions and highly correlated quantitative and/or qualitative attributes . The strength of correl-
42
ative relationships between the outcomes and each attribute were indicated by the relative importance of each
attribute to the predictive accuracy of the random forest. The significance of these relationships was assessed with
the Boruta algorithm. The Boruta algorithm tests the significance and predictive accuracy of each attribute by
comparing the observed score against a set the randomly permuted attributes (500 permutations across objects).
Hence, this provides inference about the attribute importance, which may be either confirmed (importance
higher than random) or rejected (importance lower than random probes), although in some cases the attribute
may be judged neither confirmed nor rejected and thus finally marked as tentative . The set of relevant attributes
43
may contain correlated and redundant variables. Also, the correlation of the attribute with the outcomes does not
imply causative relation; it may arise when both are independently correlated with a third variable.
The random forest algorithm implemented in the R package randomForest has three hyperparameters known
58
to affect RF model predictive accuracy and attribute importance estimates: (1) ntree, the number of trees grown,
(2) mtry, the number of attribute randomly selected when growing one tree, and (3) nodesize, the minimum size
of terminal nodes. Therefore it is crucial to tune the three hyperparameters in order to optimise the RF model.
To do so we followed the procedure described in Supplementary Methods and Supplementary Figures S2–S5.
Once the random forests were optimised and the significant, relevant, attributes were identified we assessed
59
collinearity among the eight most relevant attributes by using Kendall’s rank correlation coeffecient . P-values
under the null hypothesis of no association were obtained by normal approximation with continuity correction .
59
In order to characterise the multivariate relationships among the eight attributes identified as important (i.e.
the ones detected as significant and tentative) by Boruta (in part collinear, Supplementary Figure S1), we carried
out a Factor Analysis of Mixed Data (FAMD) by using the R package FactoMineR . The eight most important
60
attributes detected by Boruta for OMS were used as active variables. The success score was added as a supplemen-
tary variable in order to appreciate the directionality of attributes effects.
References
1. Teh, L. C. L. & Sumaila, U. R. Contribution of marine fisheries to worldwide employment. Fish. Fish. 14, 77–88 (2013).
2. Costello, C. et al. Global fishery prospects under contrasting management regimes. Proc. Natl. Acad. Sci. USA 113, 5125–5129
(2016).
3. Worm, B. Averting a global fisheries disaster. Proc. Natl. Acad. Sci. USA 113, 4895–4897 (2016).
4. McCauley, D. J. et al. Marine defaunation: animal loss in the global ocean. Science 347, 1255641, doi: 10.1126/science.1255641
(2015).
5. Pauly, D. et al. Towards sustainability in world fisheries. Nature 418, 689–695 (2002).
6. Costello, C. et al. Status and solutions for the world’s unassessed fisheries. Science 338, 517–520 (2012).
7. Hilborn, R. & Ovando, D. Reflections on the success of traditional fisheries management. ICES J. Mar. Sci. 71, 1040–10466 (2014).
8. Pauly, D. & Charles, T. Counting on small-scale fisheries. Science 347, 242–243 (2015).
9. Pauly, D. & Zeller, D. Catch reconstructions reveal that global marine fisheries are higher than reported and declining. Nat.
Commun. 7, 10244 (2016).
10. FAO. Small-scale fisheries - Web Site. Voluntary Guidelines on Securing Sustainable Small-Scale Fisheries. FI Institutional Websites. In:
FAO Fisheries and Aquaculture Department [online]. Rome. Updated 15 April 2014. [Cited 11 May 2015].
11. Jacquet, J. & Pauly, D. Funding priorities: big barriers to small-scale fisheries. Conserv. Biol. 22, 832–835 (2008).
12. FAO. The State of World Fisheries and Aquaculture: Opportunities and Challenges. Food and Agriculture Organisation of the United
Nations. FAO, Rome (2014).
13. Garcia, S. M., Zerbi, A., Aliaume, C., Do Chi, T. & Lasserre, G. The ecosystem approach to fisheries: issues, terminology, principles,
institutional foundations, implementation and outlook. FAO Fisheries Technical Paper No. 443. Rome, FAO: 71 pp (2003).
14. Halpern, B. S., Lester, S. E. & McLeod, K. L. Placing marine protected areas onto the ecosystem-based management seascape. Proc.
Natl. Acad. Sci. USA 107, 18312–18317 (2010).
15. Lubchenco, J. & Grorud-Colvert, K. Making waves: The science and politics of ocean protection. Science 350, 382–383 (2015).
16. Watson, J. E. M., Dudley, N., Segan, D. B. & Hockings, M. The performance and potential of protected areas. Nature 515, 67–73
(2014).
17. Roberts, C. M., Hawkins, J. P. & Gell, F. R. The role of marine reserves in achieving sustainable fisheries. Philos. T. R. Soc. B 360,
123–132 (2005).
18. Marine Conservation Institute. MPAtlas. Seattle, WA. www.mpatlas.org [Accessed 30/05/2016].
19. Gabrié, C. et al. The Status of Marine Protected Areas in the Mediterranean Sea. MedPAN & CAR/ASP. Ed: MedPAN Collection. 260
pp (2012).
20. Claudet, J. et al. Marine reserves: Size and age do matter. Ecol. Lett. 11, 481–489 (2008).
21. Sala, E. et al. The structure of Mediterranean rocky reef ecosystems across environmental and human gradients, and conservation
implications. PLoS ONE 7, e32742 (2012).
22. Edgar, G. J. et al. Global conservation outcomes depend on marine protected areas with five key features. Nature 506, 216–220
(2014).
23. Hughes, T. P. et al. A critique of claims for negative impacts of Marine Protected Areas on fisheries. Ecol. Appl. 26, 637–641 (2016).
24. Hilborn, R. et al. When can marine reserves improve fisheries management? Ocean. Coast. Manag. 47, 197–205 (2004).
25. Hilborn, R. Marine Protected Areas miss the boat. Science 350(6266), 1326, doi: 10.1126/science.350.6266.1326-a (2015).
26. Di Lorenzo, M., Claudet, J. & Guidetti, P. Spillover from marine protected areas to adjacent fisheries has an ecological and a fishery
component. J. Nat. Conserv. 32, 62–66 (2016).
27. Kerwath, S. E., Winker, H., Götz, A. & Attwood, C. G. Marine protected area improves yield without disadvantaging fishers. Nat.
Commun. 4, doi: 10.1038/ncomms3347 (2013).
28. Ovando, D., Dougherty, D. & Wilson, J. R. Market and design solutions to the short-term economic impacts of marine reserves. Fish.
Fish (2016).
29. Claudet, J. & Guidetti, P. Fishermen contribute to protection of marine reserves. Nature 464, 673–673 (2010).

Scientific RepoRts | 6:38135 | DOI: 10.1038/srep38135 8
