Since maxima fluctuations within the study period resulted in about m 0.4 m and the average beach slope is 3.59 %
(Figure 3) the shoreline positioning uncertainty due to tide variation is ~ m 10 m.

5. DISCUSSION AND CONCLUSIONS
The proposed methodology, even if in a preliminary phase, allows evaluating tides and waves influence in positioning
the shoreline through remotely sensed images. These are often the only tools available to build-up the morphological
evolution of a beach in the last decades with sufficient accuracy. Shoreline positioning through airborne images are often
affected by uncertainty in the user visual interpretation of the wet/dry boundary of a beach, due to both waves and
images characteristics at the acquisition time. The study case shows that wave motion, together with local sea
characteristics, produces a positioning error of about 15 meters. Shoreline and run-up delimit a zone strictly dependent
on ordinary sea storm, during which they are both submerged and that therefore should be assumed as respect zone and
should undergoes the rules of the maritime State property. Uncertainties due to sea level fluctuation, causing an error of
≈ 10 m, must be superimposed to those caused by the run-up (≈ 7.7 m). Methodology limits are strictly related to
offshore buoy data quality and availability. Run-up has been estimated using an empirical relationship retrieving an
accurate value, even if the implementing of a hydraulic model to verify shoreline position is actually in progress.
However the knowledge of maritime conditions during the remote sensing overpass is fundamental to rigorously verify
the positioning.

6. REFERENCES
[1]
Martin, B., Jack Davis, J., Kress, R., Ebersole B., and Curtis W.R., [Coastal Engineering Manual], CEM,
Washington, (2002).
[2]
Boak, E.H. and Turner, I.L., "Shoreline definition and detection: a review", Journal of Coastal Research, 18, 1-13,
(2005).
[3]
Neilsen, P., and Hanslow, D. J., "Wave run-up distributions on natural beaches", J. Coastal Res., Papers 7, 1139-
1152, (1991).
[4]
Baldock, T.E., Weir, F., and Hughes, M.G., "Morphodynamic evolution of a coastal lagoon entrance during swash
overwash", Geomorphology 95, Issues 3-4, 15, 398-411, (2008).
[5]
Andrèfouët, S., Robinson, J.A., Hu, C.M., Feldman, G.C., Salvat, B., Payri, C. And Muller-Karger, F.E., "Influence
of the spatial resolution of SeaWiFS, Landsat-7, SPOT, and International Space Station data on estimate of
landscapes parameters of Pacific Oceans atolls". Canadian Journal of Remote Sensing, 29, 210-218, (2003).
[6] Lee, J.S., and Jurkevich, I., "Coastline detection and tracing in SAR images", IEEE Transaction on Geoscience and
Remote Sensing, 28, 662-668, (1990).
[7] Baghdadi, N., Gratiot, N., Lefebvre, J.P., Oliveros, C. and Bourguignon, A., "Coastline and mudbank monitoring in
French Guaiana: contribution of radar and optical satellite imagery" Canadian Journal of Remote Sensing, 30, 109-
122, (2004).
[8]
Kim, D.J., Moon, W.M., Park, S.E., Kim, J.E. and Lee, H.S., "Dependence of waterline mapping on radar frequency
used for SAR images in intertidal areas ", IEEE Geoscience and Remote Sensing Letters, 4, 269-273, (2007).
[9]
Liu, H., Sherman, D. and Gu, S., "Automated extraction of shoreline from airborne light detection and ranging data
and accuracy assessment based on Monte Carlo simulation" Journal of Coastal Research, 23, 1359-1369, (2007).
[10]
Lee, D.S. and Shan, J.,"Combining Lidar Elevation Data and IKONOS multispectral imagery for coastal
classification mapping", Marine Geodesy, 26,105-115, (2003).
[11]
Deronde, B., Houthuys, R., Debruyn, W., Fransaer, D., Van Lancker, V. and Henriet, J.P., "Use of airborne
hyperspectral data and laserscan data to study beach morphodynamics along the Belgian coast", Journal of Coastal
Research, 22, 1108-1117, (2006).
[12] Corsini, S. and Inghilesi, R., [Atlante delle onde nei mari italiani], APAT, Roma, 5, (2006).
[13]
Boccotti, P., [Idraulica Marittima], UTET, Torino, (2008).
[14] Whitham, G.B., [Linear and Nonlinear Waves], John Wiley and Sons Inc., New York, (1974).
[15]
Mei, C.C., [The applied dynamics of ocean surface waves], John Wiley, New York, (1983).
[16] Komen, G.J., [Dynamics and Modelling of Ocean waves], Cambridge University Press, 532, (1994).
[17]
Stockdon, H.F., Holman, R.A., Howd, P.A., Sallenger Jr, A.H., "Empirical parameterization of setup, swash and
runup", Coastal Engineering, Papers 53 (7), 573-588, (2006).
[18]
Ruggieri, G., and Unti, M., "Pliocene e Pleistocene nell’entroterra di Marsala". Bollettino Società Geologica Italiana
93, 723-733, (1974).
